PULS SL4.100 DIN-rail Power Supply
PULS SL4.100 DIN-rail Power Supply
- Model: SL4.100
$0.00
Ex Tax: $0.00
PULS SL4.100 FEATURES
- Input: AC 230V / 115V, DC 210-375V
- Output: 24V / 4A
- 100 VA Limited Power Source
- No switch-off at overload
- Quasi-Wide-Range Input
- Robust mechanics and EMC
- NEC Class 2 Power Supply
Over 40 Years in Business
Successful track record across Canada
Full Engineering Services
A powerhouse to provide consultation, training, and support
Strong Brand Portfolio
Top-notch products from superb global and local suppliers
Advanced Technologies
From legacy and mainstream to advanced Industry 4.0
PULS SL4.100 INTRODUCTION
The SL4.100 is a DIN-rail power supply with AC 230V / 115V, DC 210 - 375V Input.
As an Authorized Distributor of PULS, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy PULS SL4.100 DIN-rail Power Supply online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.
You can also find the SL5.105 and SL5.102 models in the PULS DIN-rail Power Supplies for 1-phase Systems Series.
PULS SL4.100 CERTIFICATIONS

| PULS Power Supply : Input Data | |
| Input Voltage Range | AC: 85 to 264 VAC, DC: 210 to 375 VDC |
| Nominal Input Voltage | - |
| Input Frequency Range | 47 to 63 Hz |
| Input Current | AC: Switch in 115V position: < 2.0A / switch in 230V position: < 1.1A |
| Power Factor | - |
| Crest Factor | - |
| Inrush Current | At 264V: typ. < 15 A |
| Input Fuse | No |
| PULS Power Supply : Output Data | |
| Output Voltage Range | 24 to 28 V |
| Nominal Output Voltage | 24 VDC |
| Output Current | 4 A at 24 V |
| Output Power | 96 W |
| Power Boost | - |
| Output Capacitance | - |
| PULS Power Supply : Protection Features | |
| Overload Protection | Yes |
| Reverse Input Polarity Protection | No |
| Over-Temperature Protection | No |
| Input Transient Protection | No |
| Output Transient Protection | No |
| Short Circuit Protection | Yes |
| Output Overvoltage Protection | Yes: typ. 29V |
| PULS Power Supply : General | |
| MTBF | No |
| Connection Method | Screw terminals |
| AC/DC OK | AC/DC: Yes |
| LED Indicators | 1 green LED |
| Remote ON / OFF Function | - |
| IO-Link Interface | - |
| PULS Power Supply : Physical Characteristics | |
| Operating Temperature | -10° to 70°C |
| Storage Temperature | -25° to 85°C |
| Relative Humidity Range | 5 to 95% r.H |
| Altitude Range | - |
| Derating | Between +60 to +70 °C: typ. 3 W/K |
| Dimensions | 64 mm x 124 mm x 103 mm |
| Weight | 620 g |
| Mounting Type | DIN rail |
| Housing | Sealed metal |
| Standards and Certifications | IEC 60950, UL 508, UL 60950, EMC |
