PULS SLD2.100 DC/DC Converter
PULS SLD2.100 DC/DC Converter
- Model: SLD2.100
$0.00
Ex Tax: $0.00
PULS SLD2.100 FEATURES
- DC/DC converter for the SilverLine
- Input: DC 18 to 36 V
- Output: 5.1 V / 8 A
- MOSFET inverse battery protection
- Active in-rush current limiting
Over 40 Years in Business
Successful track record across Canada
Full Engineering Services
A powerhouse to provide consultation, training, and support
Strong Brand Portfolio
Top-notch products from superb global and local suppliers
Advanced Technologies
From legacy and mainstream to advanced Industry 4.0
PULS SLD2.100 INTRODUCTION
The PULS DC/DC Converter Series with DC 18 to 36 V Input.
As an Authorized Distributor of PULS, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy PULS SLD2.100 DC/DC Converter online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.
PULS SLD2.100 CERTIFICATIONS

| PULS Power Supply : Input Data | |
| Input Voltage Range | DC: 18 to 36 VDC |
| Nominal Input Voltage | - |
| Input Frequency Range | - |
| Input Current | At 18 V: < 2.9 A, At 36 V: < 1.5 A |
| Power Factor | - |
| Crest Factor | - |
| Inrush Current | typ. < 5.1 A |
| Input Fuse | No |
| PULS Power Supply : Output Data | |
| Output Voltage Range | 5 to 5.5 V |
| Nominal Output Voltage | 5 VDC |
| Output Current | 8 A at 5 V |
| Output Power | 40 W |
| Power Boost | - |
| Output Capacitance | - |
| PULS Power Supply : Protection Features | |
| Overload Protection | No |
| Reverse Input Polarity Protection | No |
| Over-Temperature Protection | No |
| Input Transient Protection | No |
| Output Transient Protection | No |
| Short Circuit Protection | No |
| Output Overvoltage Protection | Yes: typ. 6 V |
| PULS Power Supply : General | |
| MTBF | SN 29500: 510000 h |
| Connection Method | Screw terminals |
| AC/DC OK | DC: Yes |
| LED Indicators | 1 green LED |
| Remote ON / OFF Function | - |
| IO-Link Interface | - |
| PULS Power Supply : Physical Characteristics | |
| Operating Temperature | 0° to 70°C |
| Storage Temperature | -25° to 85°C |
| Relative Humidity Range | 5 to 95% r.H |
| Altitude Range | - |
| Derating | Between+60° to +70°C: typ. 1.5 W/K |
| Dimensions | 49 mm x 124 mm x 102 mm |
| Weight | 470 g |
| Mounting Type | DIN rail |
| Housing | - |
| Standards and Certifications | EMC |
