BALLUFF BES0227 INDUCTIVE STANDARD SENSOR

BALLUFF BES0227 INDUCTIVE STANDARD SENSOR
  • Model: BES0227
$0.00
Ex Tax: $0.00

    BALLUFF BES0227 FEATURES

    • Connection: M12x1-Male, 4-pin, A-coded
    • Operating temperature: -25 to 70 °C
    • IP rating: IP67
    • Shielded and unshielded versions
    • Plug or cable connection
    Over 40 Years in Business
    Over 40 Years in Business
    Successful track record across Canada
    Full Engineering Services
    Full Engineering Services
    A powerhouse to provide consultation, training, and support
    Strong Brand Portfolio
    Strong Brand Portfolio
    Top-notch products from superb global and local suppliers
    Advanced Technologies
    Advanced Technologies
    From legacy and mainstream to advanced Industry 4.0

    BALLUFF BES0227 INTRODUCTION

    Balluff BES standard inductive sensors for detecting electrically conductive metallic objects are robust and reliable. With a wide range of over 500 model series, we offer the right inductive sensor for every application.

    The technology, which is in use worldwide, has an optimum price/performance ratio and can also be delivered in a short amount of time, even in large quantities.


    As an Authorized Distributor of BALLUFF, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy BALLUFF BES0227 INDUCTIVE STANDARD SENSOR online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.

    You can also find the BES060R and BES060M models in the BALLUFF Inductive Standard Sensors.

    BALLUFF BES0227 CERTIFICATIONS



    Inductive Sensors : Interface
    Output Characteristic PNP normally open (NO)
    Inductive Sensors : Electrical Connection
    Connection M12x1-Male, 4-pin, A-coded
    Polarity Reversal Protected Yes
    Inductive Sensors : Electrical Data
    Protection Class II
    Ripple 10 %
    Switching Frequency 50 Hz
    Operating Voltage Ub 10 to 55 VDC
    Current (Ie) 200 mA
    Inductive Sensors : Range/Distance
    Measuring Range 40 mm
    Assured Operating Distance Sa 32 mm
    Real Switching Distance sr 40 mm
    Inductive Sensors : Physical and Environmental Characteristics
    Dimension 106 x 80 x 40 mm
    Weight -
    Installation for flush mounting
    Operating Temperature -25 to 70 °C
    Housing PBT
    IP Rating IP67
    Tightening Torque 3 Nm
    MTTF 455 a
    Standards and Approvals CE, UKCA, WEEE, IEC 60947-5-2
