MOXA ICF-1150I-S-SC-IEX Serial to Fiber Converter
- Model: ICF-1150I-S-SC-IEX
MOXA ICF-1150I-S-SC-IEX FEATURES
- EX-Approved Serial to Fiber Converter
- 1 x RS-232/422/485 Serial port (DB9-F, TB)
- 1 x 100BaseFX Port (Single-mode SC connector)
- 2 KV Isolation protection for serial ports
- 40 KM Typical data transmission distance on fiber
- 12 to 48 VDC input power range
- IP30-rated Metal body design
- DIN-rail mounting
- 0 to 60°C operating temperature range
MOXA ICF-1150I-S-SC-IEX INTRODUCTION
The ICF-1150
serial-to-fiber converters transfer RS-232/RS-422/RS-485 signals to optical
fiber ports to enhance transmission distance. When an ICF-1150 device receives
data from any serial port, it sends the data through the optical fiber ports.
These products not only support single-mode and multi-mode fiber for different
transmission distances, but models with isolation protection are also available
to enhance noise immunity. The ICF-1150 products feature three-way
communication and a rotating switch to set the pull high/low resistor for
on-site installation.
Three-Way Communication
The ICF-1150 Series
supports 2 serial ports, with a DB9 connector for RS-232 communication and a
removable terminal block for RS-422 or RS-485 communication. The 3 ports (2
serial ports and one fiber port) are completely independent. When an ICF-1150
converter receives data from any one port, it will send the data through the
other 2 ports. For example, once the ICF-1150 converter receives a command from
the remote master through the fiber port, it will convert the signal and send
the command through the RS-232 and RS-422/485 ports at the same time. If the
user is monitoring a system running on an RS-485 network, there is no need to
use an additional RS-232 to RS-485 converter to connect the laptop computer’s
serial port to the RS-485 bus.
Rotary Switch for Setting the Pull High/Low Resistor
The RS-485 interface
supports multidrop or daisy-chain connections, which system engineers will use
to connect serial devices such as meters, RTUs, and readers together on the
same bus. Since the number of serial devices on the same bus will cause the impedance
of the data line to increase, the ICF-1150 allows users to tune the pull
high/low resistor. Just rotate the switch to the appropriate value without
removing the ICF-1150 from the DIN rail.
As an Authorized Distributor of MOXA, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy the MOXA ICF-1150I-S-SC-IEX Serial to Fiber Converter online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.
You can also find the ICF-1150-S-SC-IEX, ICF-1150I-M-SC-IEX, and ICF-1150-S-SC models in the MOXA ICF-1150 Series.
