MOXA MDR-60-24 DIN-rail Power Supply

MOXA MDR-60-24 DIN-rail Power Supply
  • Model: MDR-60-24
$0.00
Ex Tax: $0.00

MOXA MDR-60-24 FEATURES

  • 85 to 264 VAC, 120 to 370 VDC Input power range
  • 24 VDC (60 W) Output power range
  • DIN-rail mounting
  • -20 to 70°C operating temperature range


Over 40 Years in Business
Over 40 Years in Business
Successful track record across Canada
Full Engineering Services
Full Engineering Services
A powerhouse to provide consultation, training, and support
Strong Brand Portfolio
Strong Brand Portfolio
Top-notch products from superb global and local suppliers
Advanced Technologies
Advanced Technologies
From legacy and mainstream to advanced Industry 4.0

MOXA MDR-60-24 INTRODUCTION

The MDR Power Supply Series supports inrush current protection of 30 A at 115 VAC and 60 A at 230 VAC. The series has an operating temperature range of -20 to 70°C and a three-year warranty, which ensures suitability for operating in harsh environments. In addition, the MDR Series has passed a 100% full load burn-in test, is UL/CUL listed, TÜV/CB certified, and CE marked. There are also models available with output ratings from 40 W to 60 W with 24 VDC output.

As an Authorized Distributor of MOXA, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy the MOXA MDR-60-24 DIN-rail Power Supply online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.

You can also find the MDR-40-24 model in the MOXA MDR Power Supply Series.

MOXA MDR-60-24 CERTIFICATIONS



Power Supply : Power Requirements
Input Voltage: 85 to 264 VAC (47 to 63 Hz), 120 to 370 VDC; Typical Current: 1.0 A @ 230 VAC, 1.8 A @ 115 VAC; Typical Current (cold start): 60 A @ 230 VAC, 30 A @ 115 VAC
Operating Voltage -
Output Wattage: 60 W; Voltage: 24 VDC; Current Rating: 0 to 2.5 A
Over-voltage Protection 31.2 to 36 V (Shut down operating voltage, repower on to recover)
Overload Protection 105 to 150% (Constant current limiting, recovers automatically after fault condition is removed)
Reverse Polarity Protection -
Power Supply : Physical Characteristics
Dimensions 40 x 90 x 100 mm (1.57 x 3.54 x 3.94 in)
Housing -
Weight 280 g
Ambient Relative Humidity 20 to 90% (non-condensing)
Operating Temperature -20 to 70°C (-4 to 158°F)
Storage Temperature -
Installation DIN-rail mounting
Standards and Certifications Safety: UL 508, EN 62368-1, IEC 62368-1; EMC: EN 55032/35, EN 61000-3-2 Class A, EN 61000-3-3, EN IEC 61204-3, EN IEC 61000-6-2; EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m, IEC 61000-4-4 EFT: Power: 2 kV, IEC 61000-4-5 Surge: Power: 4 kV, IEC 61000-4-6 CS: 0.15 kHz to 80 MHz: 10 Vrms, IEC 61000-4-8 PFMF: 30 A/m, IEC 61000-4-11
MTBF -
Power Supply : Supported Series
Supported Series -
