MOXA EDS-4008-2SSC-LV Managed Ethernet Switch
MOXA EDS-4008-2SSC-LV FEATURES
- 6 x 10/100BaseT(X) Ports (RJ45 connector)
- 2 x 100BaseFX Ports (single-mode SC connector)
- 40 KM Typical data transmission distance on fiber
- 12/24/48 VDC Redundant dual power inputs
- Pre-installed PWR-100-LV Power Module
- DIN-rail and wall mounting
- IP40-rated Metal body design
- -10 to 60°C operating temperature
MOXA EDS-4008-2SSC-LV INTRODUCTION
The Moxa EDS-4008-2SSC-LV managed Ethernet switch is an
industrial-grade solution designed explicitly for rugged environments like
power utility, railway transportation, road transportation, marine, and factory
automation industries. The Moxa industrial network infrastructure strives to
facilitate robust performance in demanding industrial settings. The
EDS-4008-2SSC-LV switch is no exception. With a comprehensive list of industry
standards, including certification for use in hazardous locations, this layer 2 managed Ethernet switch guarantees safety and uninterrupted operations.
Robust Ethernet Connectivity
The Moxa EDS-4008-2SSC-LV switch features six 10/100BaseT(X)
ports with auto-negotiation speed, Full/Half duplex mode, and auto MDI/MDI-X
connection capabilities. It allows access to two 100BaseFX single-mode ports
with SC connectors, providing the flexibility and speed necessary for various
industrial networking applications. The EDS-4008 series comes with such
capabilities to ensure the highest reliability and connectivity.
Reliable Power Inputs and Operating Voltage
The Moxa EDS-4008-2SSC-LV managed switch meets rigorous
industrial requirements by sporting a redundant dual input voltage of 12/24/48
VDC. It also covers operating voltages from 9.6 to 60 VDC with a maximum power
consumption of 8.98 W. To ensure safety in industrial applications, the switch
comes with built-in overload current protection and reverse polarity
protection. These protections ensure reliable operation in challenging
environments. Refer to the Moxa EDS-4008-2SSC-LV datasheet for more information.
As an Authorized Distributor of MOXA, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy MOXA EDS-4008-2SSC-LV Managed Ethernet Switch online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.
You can also find the EDS-4008-2SSC-LV-T, EDS-4008-2SSC-HV, EDS-4008-2SSC-HV-T, and EDS-4008-2MSC-LV models in the MOXA EDS-4008 Series.
MOXA EDS-4008-2SSC-LV CERTIFICATIONS
The Moxa EDS-4008-2SSC-LV ethernet switch complies with
various industrial standards to ensure safe and flawless performance in
industrial environments. This switch is compliant with electromagnetic
compatibility standards EMC, EMI, EMS, and environmental robustness. Also, it
includes industrial certifications, such as UL 61010-2-201, EN 62368-1 (LVD)
for safety, DNV, ABS, NK, and LR for maritime, EN 50121-5 for railway
applications, and NEMA TS3 for traffic control environments. Moreover, the
EDS-4008-2SSC-LV is certified for shock and vibration resistance, along with
IEC 61850-3 and IEEE 1613 Class 2 standards. Last but not least, this switch
meets IEC 62443-4-1 and IEC 62443-4-3 standards that protect critical
infrastructure from emerging cyber threats.
