MOXA M-3810 Remote I/O Module

MOXA M-3810 Remote I/O Module
  • Model: M-3810
$0.00
Ex Tax: $0.00

MOXA M-3810 FEATURES

  • 8 x Analog Input Channels (0-10 V)
  • Plastic body design
  • DIN-rail mounting
  • -10 to 60°C operating temperature
Over 40 Years in Business
Over 40 Years in Business
Successful track record across Canada
Full Engineering Services
Full Engineering Services
A powerhouse to provide consultation, training, and support
Strong Brand Portfolio
Strong Brand Portfolio
Top-notch products from superb global and local suppliers
Advanced Technologies
Advanced Technologies
From legacy and mainstream to advanced Industry 4.0

MOXA M-3810 INTRODUCTION

The ioLogik 4000 Series is suitable for remote monitoring and alarm systems, such as those used for water treatment systems, water supply systems, wastewater treatment systems, and power monitoring systems. These kinds of applications need more I/O points and a variety of I/O types, including temperature sensors, gas detectors, and water quality detectors, all of which can benefit from the versatile mixture of I/O features supported by the ioLogik 4000 Series.

As an Authorized Distributor of MOXA, Manufacturers Automation Inc. (ManuAuto) offers a wide variety of Industrial Automation and Communication products across North America, including Canada (Ontario, Toronto) and the US. Buy the MOXA M-3810 Remote I/O Module online at a competitive price, with on-time delivery and fast shipping services. Our certified engineers are always available to support you.

End-of-Life Product - Replacement Available

Please note that the ioLogik 4000 Series (M) Modules have been phased out and replaced by the MOXA 45MR Series.

MOXA M-3810 CERTIFICATIONS



Remote I/O Modules : Input/Output Interface
Digital Input and Output No
Analog Input and Output Yes : 8 x Analog Input Channels (0-10 V)
System Power Input Channels No
Field Power Input and Output No
Thermocouple Channels No
RTD Channels No
CAN Ports No
Ethernet Ports No
Relays No
Serial Ports No
Isolation Yes : 3k VDC or 2k Vrms
Remote I/O Modules : Serial Interface
Connector -
Serial Standards -
Serial Communication Parameters -
Serial Signals -
Remote I/O Modules : General
MTBF 7,288,320 hrs
Remote I/O Modules : Power Requirements
Power Connector Spring-type Euroblock terminal
Input Voltage -
Power Consumption 60 mA @ 5 VDC
Remote I/O Modules : Physical Characteristics
Housing Plastic
Dimensions 14.1 x 99 x 70 mm (0.56 x 3.90 x 2.76 in)
Weight Under 80 g
Installation DIN-rail mounting
Operating Temperature -10 to 60°C (14 to 140°F)
Storage Temperature -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity 5 to 95% (non-condensing)
Standards and Certifications EMC: EN 55032/24, EN 61000-6-2/-6-4; EMI: CISPR 32, FCC Part 15B Class A; EMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV, IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m, IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV, IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV, IEC 61000-4-6 CS: 10 V, IEC 61000-4-8 PFMF; Safety: UL 508; Shock: IEC 60068-2-27; Vibration: IEC 60068-2-6; Green Product: RoHS, CRoHS, WEEE; RoHS, CRoHS, WEEE
Altitude -
